FlexLED Chameleon 24V (Fully Bendable)

I24VCHAM273002835

12 items left


Collections: 24VDC FlexLED Tape PRO

Type: Flexible LED Tape


Fully Bendable FlexLED Tape.
Bendable in any direction, this tape is lower powered than our standard FlexLED but is extremely useful in many situations where standard linear FlexLED will not work.

Suitable for residential, television, industrial, commercial applications, and signage applications.

Available in 2700k/3000k/4100k/5600k/RGB/RGBA/RGB+W

3M double-sided tape on the back makes installation as easy as peel n stick.
Controller, power supply and extension cables sold separately
Custom color temperatures available. Please call to inquire.

RGB and RGBA variants are currently non-stock items and may take 3 - 4 weeks for delivery.

Soldering Guidelines:
Soldering iron should be between 360°C and 372°C.  Please ensure not to heat each solder pad for longer than 3 seconds otherwise separation of the solder pads can occur.



SPECIFICATIONS - INDOOR PRODUCT

Product Type : Chameleon White Chameleon RGB Chameleon RGBA Chameleon RGB+W
Product Code : I24VCHAMXX3002835 I24VCHAMRGB2105050 I24VCHAMRGBA2405050 I24VCHAMRGBWXX2405060
CRI : ⩾90 N/A N/A ⩾90
Kelvin : 2700k / 3000k / 4100k / 5600k N/A N/A Colour Changing + 2700k / 5600k
PCB Color : White White White White
Current, Rating : 0.45 A / meter 0.6 A / meter 0.6 A / meter 0.64 A / meter
Voltage : 24 VDC 24 VDC 24 VDC 24 VDC
Wattage : 10.8 W / meter 10.08W / meter 15.36W / meter 15.4W / meter
CC / CV : Constant Voltage Constant Voltage Constant Voltage Constant Voltage
IP Rating : IP43 IP43 IP43 IP4
Lumens @ Full : 926.4 lm / meter @ 2700k
1097 lm / meter @ 5600k
XX lm / meter XX lm / meter 345.4 lm / meter @ 5600k @ Full
Lumen / Watt : 83.32 @ 2700k - 98.52 @ 5600k N/A N/A 87.6
Lifetime* : 30,000 hours 30,000 hours 30,000 hours 30,000 hours
Cutting Length : 10 CM 10 CM 10 CM 12.5 CM
LED Quantity : 60 LED / meter 42 LED / meter 48 LED / meter 48 LED / meter
Number of Contacts : 2 4 5 5
LED Type : 2835 5050 5050 5050
Copper Quantity : 1 Oz. 1 Oz. 1 Oz. 1 Oz.
Temperature, Operating, Maximum : 70 C 70 C 70 C 70 C
Temperature, Operating, Minimum : -40 C -40 C -40 C -40 C
Agency Ratings : UL - E489028, CE, RoHS UL - E489028, CE, RoHS UL - E489028, CE, RoHS UL - E489028, CE, RoHS
PCB Width : 6.5MM 12MM 12MM 12MM
Maximum Recommended Length : 2 meters 5 meters 5 meters 5 meters
Viewing Angle : 120 120 120 120
Adhesion : 200MP 3M 200MP 3M 200MP 3M 200MP 3M

DOWNLOADS

*nominal lifetime - dependent on installation location
