24V Battery Holder

10" Round Aluminum LED Panel

$154.56 CAD

• High output rigid LED panel with excellent output with only a 42W draw
• Rigid aluminum panel acts as a heat-sink and protects longevity of LEDs
• Center hole on panel allows for easy mounting

DMX Dimmer 3 / 4 Channel 16-Bit

$87.81 CAD

*THIS MODEL IS DISCONTINUED - LIMITED QUANTITY REMAINING*

This 3-Channel Controller can be used with all of our FlexLED Tape lines and Modules

• Uses terminal blocks to control LEDs via any lighting console or through computer software
• Can create over 16 million colours when used with our Colourful (RGB) FlexLED Tape
• LCD Menu readout allows for adjustments from 8-bit mode to 16-bit mode and addressing properties.

Technical Parameters

• Working temperature: -20-60 C
• Supply voltage: 5V,12-24V
• Output: 3 channel OR 4 channel
• External dimension: L165*W68*H40mm
• Packing size: L180*W95*H60mm
• Net weight: 320g
• Gross weight: 355g
• Output current: each channel 4A
• Output power: 5V:<60W, 12V:<144W, 24V:<288W

**Connector Tails Not Included**

Dual-Quad-LED DMX Dimmer

$281.04 CAD

This controller can be used with all of our FlexLED Tape products and Modules

• This unit is beefy! 5A X 24 Channel = MAX 120A!
• 24 Channel DMX Decoder - 16 Bit - High Current.
• This unit converts DMX-512/1990 standard digital signal into 24 dimmable channels.
• Uses RJ45 Ethernet or 5-pin XLR connectors to control LEDs via any lighting console or through computer software.
• Can create over 16 million colors when used with our Colorful (RGBA or RGBW or RGB OR Bi-Color OR White) FlexLED Tape.
• Dip Switch No. 10 is Termination for DMX.
• Dip Switch No. 11 is Frequency Option (500Hz or 5kHz).
• Dip Switch No. 12 is Bit-Rate Option 16 Bit or 8 Bit.

Technical Parameters

• Supply Voltage: 12V - 24V DC
• Output: 24 Channels
• Output Current: 24 CH @ 5A/CH = Max 120A
• Output Power: 1440W @ 12V / 2880W @ 24V
• PWM Frequency: 500Hz OR 5000Hz (5KHz)
• Signal Isolation: > 1000V
• Bit Rate: 8 Bit & 16 Bit
• External Dimension (mm): L290*W122*H33
• Gross Weight: 920g
• Working Temperature: 0C to +70C
• IP Rating: IP40

**Connector Tails Not Included**

Edison Plug - HBL8115V

$14.96 CAD
