MossLED Cinque-LED DMX Dimmer V3.4 5-channel 7A DMX512 decoder front view with LED display green terminal blocks and control buttons

Cinque-LED DMX Dimmer

SKU CONTDMX5CH12V24VLCD
by MossLED

Qty Discount
10 3%
21 6%
51 9%
The more you buy, the more you save!
$110.60
Type

Total Availability Total product quantity available to order. Product may ship from one warehouse or both warehouses, if required. If product needs to transfer from one warehouse to the other before shipping, a 24-hour delay may occur.

1064 in stock

Location Quantity available at each warehouse location. Orders shipping from a single warehouse ship faster; orders requiring stock from both warehouses may be delayed by up to 24 hours for transfer.

Canadian Warehouse Ships from 1355 Fewster Drive, Mississauga, Ontario, L4W 1A2 Canada : 532 in stock
USA Warehouse Ships from 6405 Inducon Dr W, Sanborn, NY 14132, United States : 532 in stock

The Cinque-LED DMX Dimmer is a versatile, high-precision LED controller, delivering powerful dimming capabilities for film, television, theatrical, and architectural lighting applications. With rugged metal housing, professional-grade DMX connectivity, and 40A total power handling, it provides smooth dimming control, flexible installation, and superior performance.

Key Features:

  • 5-Channel DMX Dimming – Converts DMX-512/1990 signals into precise LED control.
  • High Current Capacity – Supports 40A total output (5 x 8A per channel).
  • Adjustable PWM Frequency – 500Hz to 35kHz for flicker-free performance on-camera.
  • 8-bit & 16-bit Resolution Modes – Ensures smooth, precise dimming and colour transitions.
  • Customizable Gamma Curve – Fine-tune low-end or high-end dimming response.
  • Industry-Standard DMX Connectivity – Features 5-pin XLR and RJ45 Ethernet in/out for seamless integration.
  • Easy-to-Read LED Display – Enables DMX addressing, manual mode, and test functions.
  • Compatible with FlexLED Tape & Modules – Works with RGBA, RGBVW, RGBW, RGB, Bi-Colour, and White LED strips.
  • RDM Remote Device Management for adjusting DMX address, PWM frequency and more.

The Cinque-LED DMX Dimmer is an advanced, standalone LED controller, built for reliable, high-performance lighting control in professional environments.

Need a custom solution? Contact us today!








    *For Constant Current model, pls refer to its User Manual.
    Refer to Installation Guide Prior to Installing.



    DOWNLOADS

    1. UL Certificate of Compliance
    2. Constant Voltage Cinque Installation Instructions 2025-06-02
    3. Constant Voltage Cinque Manual 2025-06-16
    4. Constant Current 1000MA Cinque Manual v3.2
    5.  RoHS Certificate
    6.  CE Certificate of Conformity

    Specifications

    ⚲
