The FlexLED Bi-Color 2700K - 6000K 24V is a high-density, colour temperature adjustable LED strip, delivering smooth, tunable white light with CRI 95+ for professional lighting applications. Available in four pixel configurations, 120, 196, 240 and 480 LED/m versions, this strip provides flexibility for projects requiring either standard or high-output illumination. Ideal for residential, television, industrial, and commercial environments, the FlexLED Bi-Color ensures accurate colour temperature shifts with a single-bin LED chip calibrated to ±100K.
Key Features:
- Adjustable White Light (2700K - 6000K) – Seamlessly transitions from warm to cool white.
- Three Density Options – 120 LED/m (12mm width) for standard applications, 196 LED/m (10mm width) for high output, 240 and 480 LED/m for maximum brightness.
- High CRI (95+) – Ensures true-to-life colour accuracy with no green spike.
- Durable & Efficient – 196, 240 and 480 LED/m versions require installation on a metal heat sink for longevity.
- Easy Peel-and-Stick Installation – TESA 4965 high-tack adhesive backing for secure mounting.
Installation & Handling Considerations:
- Indoor and weatherproof strips feature 3M adhesive backing for easy installation.
- Waterproof versions require mounting via silicone (not included).
Soldering Guidelines:
- Use a soldering iron between 360°C and 372°C (680°F ~ 702°F)
- Limit heating of each solder pad to a maximum of 3 seconds to avoid separation.
Additional Details:
- Maximum run length: 10 meters (32.81’) – Power required at both ends to avoid line loss.
- Controller, power supply, and extension cables sold separately.
- Quantity discounts and custom colour temperatures available.
- Pricing is for 5 meters (16.4’) - custom lengths available
The FlexLED Bi-Color 2700K - 6000K 24V is the perfect solution for professional-grade lighting applications, offering smooth, flicker-free dimming and precise colour temperature control.
Need a custom solution? Contact us today!
SPECIFICATIONS - INDOOR PRODUCT
| Product Type | : | Bi-Color 120 |
Bi-Color 196 |
Bi-Color 240 |
Bi-Color 480 |
| Product Code | : | I24VBC27606003528 | I24VBC27609803528 | I24VBC276012003528 | I24VBC276024003528 |
| CRI | : | ≥95 | ≥95 | ≥95 | ≥95 |
| Kelvin | : | 2700k - 6000k | 2700k - 6000k | 2700k - 6000k | 2700k - 6000k |
| PCB Color | : | White | White | White | White |
| Current, Rating | : | 0.79 A / meter | 1.4 A / meter | 1.59 A / meter | 1.59 A / meter |
| Voltage | : | 24 VDC | 24 VDC | 24 VDC | 24 VDC |
| Wattage | : | 19.2 W / meter | 33.6 W / meter | 38.4 W / meter | 38.4 W / meter |
| Wattage @ 5 Meters (Powered at one end) | : | 94 W | 139 W | 165 W | 163 W |
| Wattage @ 5 Meters (Powered at both ends) | : | 100 W | 166 W | 185 W | 179 W |
| CC / CV | : | Constant Voltage | Constant Voltage | Constant Voltage | Constant Voltage |
| IP Rating | : | IP43 | IP43 | IP43 | IP43 |
| Lumens @ Full | : | 2700k: 859lm 6000k: 1008m Combined 4000k: 1800lm |
2700K: 1400lm 6000k: 1700lm Combined 4000k: 3100lm |
2700k: 1610lm 6000k: 1955lm Combined 4000k: 3565lm |
2700k: 1610lm 6000k: 1955lm Combined 4000k: 3565lm |
| Lumen / Watt | : | 94 | 94 | 94 | 94 |
| Lifetime | : | 50,000 hours | 30,000 hours | 30,000 hours | 30,000 hours |
| Cutting Length* | : | 10.00 CM | 7.14 CM | 5.00 CM | 2.50 CM |
| LED Quantity | : | 120 LED / meter | 196 LED / meter | 240 LED / meter | 480 LED / meter |
| Number of Contacts | : | 3 | 3 | 3 | 3 |
| LED Type | : | 3528 | 3528 | 3528 | 3528 |
| Copper Quantity | : | 3 Oz. | 3 Oz. | 3 Oz. | 3 Oz. |
| Temperature, Operating, Maximum | : | 70 C | 70 C | 70 C | 70 C |
| Temperature, Operating, Minimum | : | -40 C | -40 C | -40 C | -40 C |
| Agency Ratings | : | UL - E489028, CE, RoHS | UL - E489028, CE, RoHS | UL - E489028, CE, RoHS | UL - E489028, CE, RoHS |
| PCB Width | : | 12MM | 10MM | 12MM | 28MM |
| Maximum Recommended Length | : | 10 meters | 5 meters | 5 meters | 5 meters |
| Viewing Angle | : | 120 degree | 120 degree | 120 degree | 120 degree |
| Adhesion | : | TESA 4965 | TESA 4965 | TESA 4965 | 3M 200MP |
* Rounded values. For high precision applications please contact our Tech. Dept. at extension 101
