Flicker Free Constant Voltage Family of Power Supplies. Dimmable from 0 - 100% means smooth dimming and 20khz PWM means flicker-free operation to the eye and on camera. Fully listed cULus LED drivers for compliance anywhere in North America. Features handy built-in junction box connections for making secure connections.
Extremely reliable and robust LED drivers designed for use with all Constant Voltage LED products. Perfect for on-camera and constant-on use with our FlexLED Tape or any constant voltage LED product. Available in 24VDC and 12VDC. Class 2 (Under 100VA), Class P, and Type HL safety including short-circuit, overload, over-voltage, over-current, and over-temperature protection. Rated for Dry, Damp, and Wet locations. Safe, powerful, flicker-free, and reliable are the cornerstones of our FFDCV line of power supplies from MossLED. Includes an amazing 5 year warranty.
30W and 60W version in both 12V and 24V share the same SKUs as our Flicker-Free DImmable Fanless LED Drivers without junction box as both types include a junction box.
Key Product Family Features:
| Model | : | FFDCV-24030-DDWJ | FFDCV-24060-DDWJ | FFDCV-24096-DDWJ | FFDCV-24120-DDWJ | FFDCV-24200-DDWJ | FFDCV-24300-DDWJ |
| Current (A) @ 24VDC | : | 1.25 A | 2.5 A | 4 A | 5 A | 8.34 A | 12.5 A |
| Output Power (W) | : | 30 W | 60 W | 96 W | 120 W | 200 W | 300 W |
| Agency Approvals | : | FCC UL cUL Class 2 Class P SELV UL1310 and UL8750 CSA-C22.2.NO.250.13 | |||||
| Size (millimeters) | : | 155 X 54 X 20 | 178 X 61 X 24 | 230 X 70 X 43 | 230 X 70 X 43 | 256 X 78 X 47 | 276 X 78 X 47 |
| Ripple & Noise (mV p-p) | : | 150mVp-p | |||||
| Load Regulation () | : | ±1 % | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Line Regulation () | : | ±1 % | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Efficiency | : | 79%@120VAC 80%@277VAC | 83%@120VAC 84%@277VAC | 83%@120VAC 88%@ 230VAC 87%@277VAC | 83%@120VAC 88%@ 230VAC 87%@277VAC | 83%@120VAC 88%@ 230VAC 87%@277VAC | 83%@120VAC 88%@ 230VAC 87%@277VAC |
| Frequency Range | : | 47 ~ 63 Hz | |||||
| Universal AC input | : | 100-277VAC | 90 ~ 305VAC 127 ~ 431VDC | 90 ~ 305VAC 127 ~ 431VDC | 90 ~ 305VAC 127 ~ 431VDC | 90 ~ 305VAC 127 ~ 431VDC | |
| Low leakage current | : | <0.5mA | |||||
| Protections: | : | Short Circuit, Overload, Over Temp, Auto Recovery | |||||
| Input Connector Type | : | Terminal Block | Bare Wire - Stripped & Tinned | Bare Wire - Stripped & Tinned | Bare Wire - Stripped & Tinned | Bare Wire - Stripped & Tinned | |
| Housing | : | Plastic housing | Fully Enclosed Aluminum Housing | ||||
| Ingress Protection Rating | : | Dry, Damp and Wet Locations | |||||
| Class | : | TYPE HL - Class P - Class 2 | TYPE HL - Class P | ||||
| Indicator | : | None | |||||
| Voltage Adjustment Range | : | +/- 1V | +/- 1V | Fixed | Fixed | Fixed | Fixed |
| Output Connector Type | : | Terminal Block | Bare Wire - Stripped & Tinned | ||||
| Current Adjustment Range | : | N/A | N/A | N/A | N/A | N/A | |
| Output Polarity | : | N/A | N/A | N/A | N/A | N/A | |
| Input Connector | : | Terminal Block | Bare Wire | Bare Wire | Bare Wire | Bare Wire | |
| Product Type | : | AC to DC LED Dimmable Driver | |||||
| MFR Product Family | : | FFDCV | |||||
| Operating Temperature (Ambient) | : | -40 °C to 60 °C | -40 °C to 80 °C | -40 °C to 90 °C | -40 °C to 90 °C | ||
| Power Supply Color | : | White | Dark Grey | Dark Grey | Dark Grey | Dark Grey | |
| Wiring Color Codes Output | : | Refer to Label on Housing | |||||
