Flicker Free Constant Voltage Family of Power Supplies. Dimmable from 0 - 100% means smooth dimming and 20khz PWM means flicker-free operation to the eye and on camera. Fully listed cULus LED drivers for compliance anywhere in North America..
Extremely reliable and robust LED drivers designed for use with all Constant Voltage LED products. Perfect for on-camera and constant-on use with our FlexLED Tape or any constant voltage LED product. Available in 24VDC and 12VDC. Class 2 (Under 100VA), Class P, and Type HL safety including short-circuit, overload, over-voltage, over-current, and over-temperature protection. Rated for Dry, Damp, and Wet locations. Safe, powerful, flicker-free, and reliable are the cornerstones of our FFDCV line of power supplies from MossLED. Includes an amazing 5 year warranty.
Compatible with the following dimming methods:
- TRIAC (Forward Phase / Reverse Phase / MLV / ELV)
- 0-10V
- 1-10V
- 10V PWM (External load resistor required for PWM dimming)
- Potentiometer
Key Product Family Features:
- Output 30 - 300W
- 12V and 24V constant voltage operation
- Class 2 (96 watt @ 24V and 60 watt @ 12V and below)
- Class P
- Type HL
- SELV
- 0 - 100% Dimming
- 20khz output ensures flicker-free operation
- Rated for dry, damp, and wet locations
Ships in 1 - 2 Business Days
SPECIFICATIONS - 24VDC Product
| Model | : | FFDCV-24030-DDW | FFDCV-24060-DDW | FFDCV-24096-DDW | FFDCV-24120-DDW | FFDCV-24200-DDW | FFDCV-24300-DDW |
| Current (A) @ 24VDC | : | 1.25 A | 2.5 A | 4 A | 5 A | 8.34 A | 12.5 A |
| Output Power (W) | : | 30 W | 60 W | 96 W | 120 W | 200 W | 300 W |
| Agency Approvals | : | FCC UL cUL Class 2 Class P SELV UL1310 and UL8750 CSA-C22.2.NO.250.13 | |||||
| Size (millimeters) | : | 155 X 54 X 20 | 178 X 61 X 24 | 230 X 70 X 43 | 230 X 70 X 43 | 256 X 78 X 47 | 276 X 78 X 47 |
| Ripple & Noise (mV p-p) | : | 150mVp-p | |||||
| Load Regulation () | : | ±1 % | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Line Regulation () | : | ±1 % | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Efficiency | : | 79%@120VAC 80%@277VAC | 83%@120VAC 84%@277VAC | 83%@120VAC 88%@ 230VAC 87%@277VAC | 83%@120VAC 88%@ 230VAC 87%@277VAC | 83%@120VAC 88%@ 230VAC 87%@277VAC | 83%@120VAC 88%@ 230VAC 87%@277VAC |
| Frequency Range | : | 47 ~ 63 Hz | |||||
| Universal AC input | : | 100-277VAC | 90 ~ 305VAC 127 ~ 431VDC | 90 ~ 305VAC 127 ~ 431VDC | 90 ~ 305VAC 127 ~ 431VDC | 90 ~ 305VAC 127 ~ 431VDC | |
| Low leakage current | : | <0.5mA | |||||
| Protections: | : | Short Circuit, Overload, Over Temp, Auto Recovery | |||||
| Input Connector Type | : | Terminal Block | Bare Wire - Stripped & Tinned | Bare Wire - Stripped & Tinned | Bare Wire - Stripped & Tinned | Bare Wire - Stripped & Tinned | |
| Housing | : | Plastic housing | Fully Enclosed Aluminum Housing | ||||
| Ingress Protection Rating | : | Dry, Damp and Wet Locations | |||||
| Class | : | TYPE HL - Class P - Class 2 | TYPE HL - Class P | ||||
| Indicator | : | None | |||||
| Voltage Adjustment Range | : | +/- 1V | +/- 1V | Fixed | Fixed | Fixed | Fixed |
| Output Connector Type | : | Terminal Block | Bare Wire - Stripped & Tinned | ||||
| Current Adjustment Range | : | N/A | N/A | N/A | N/A | N/A | |
| Output Polarity | : | N/A | N/A | N/A | N/A | N/A | |
| Input Connector | : | Terminal Block | Bare Wire | Bare Wire | Bare Wire | Bare Wire | |
| Product Type | : | AC to DC LED Dimmable Driver | |||||
| MFR Product Family | : | FFDCV | |||||
| Operating Temperature | : | -40 °C to 60 °C | -40 °C to 80 °C | -40 °C to 90 °C | -40 °C to 90 °C | ||
| Power Supply Color | : | White | Dark Grey | Dark Grey | Dark Grey | Dark Grey | |
| Wiring Color Codes Output | : | Refer to Label on Housing | |||||
