Dimmable Power Supply

KVP24025TDLP

$59.36 CAD

6 items left

Qty

Constant Voltage Phase/Triac dimmable drivers with PWM output.

These drivers are designed specifically to work with any standard household TRIAC wall dimmer or switch. Beautiful dimming curve from 5% - 100% allows for smooth low-end dimming that is flicker free.

Output Constant Voltage
Universal AC Input: 100 - 130VAC
High efficiency: up to 87%
Protection: short circuit / over load / over current / over temperature
Full protection plastic (25W / 60W) OR aluminum housing (96W / 200W)
Easy installation
Cooling by free air convection (no fans!)
Compatible with forward phase, magnetic low voltage, triac dimmers
Strong compatibility, flicker-free dimming
Suitable for LED Lighting, and moving sign applications and many others
Suitable for dry locations (IP20 25W / 60W)
Suitable for damp locations (IP66 96W / 200W)
cETLus Certified Class 2 (25W, 60W, 96W) and Class I (200W)

SPECIFICATIONS - INDOOR PRODUCT

Product Type	:	25 Watt	60 Watt	96 Watt	200 Watt
Product Code	:	KVP24025TDLP	KVP24060TDLP	KVP24096TDLP	KVP24200TDLJB
Certificates	:	ETL, cETL, FCC	ETL, cETL, FCC	ETL, cETL, FCC	ETL, cETL, FCC
Output Voltage	:	24V DC	24V DC	24V DC	24V DC
Output Current	:	1.04 Amps	2.5 Amps	4 Amps	8.3 Amps
Voltage Tolerance	:	+/- 0.5V	+/- 0.5V	+/- 0.5V	+/- 0.5V
Voltage	:	24 VDC	24 VDC	24 VDC	24 VDC
Input Voltage	:	100-130VAC	100-130VAC	100-130VAC	100-130VAC
Input Frequency Range	:	47 - 63Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz
Input Power Factor	:	0.65	0.65	0.65	0.65
Efficiency (typ.)	:	84%	87%	83%	85%
Input AC Current	:	0.9A	1.0A	2.0A	3.2A
Leakage current	:	<0.50mA/120VAC	<0.50mA/120VAC	<0.50mA/120VAC	<0.50mA/120VAC
Protection - Short Circuit	:	Hiccup mode, recover automatically after fault condition is removed	Hiccup mode, recover automatically after fault condition is removed	Hiccup mode, recover automatically after fault condition is removed	Hiccup mode, recover automatically after fault condition is removed
Protection - Over Current	:	<1.2*I out	<1.2*I out	<1.2*I out	<1.2*I out
Protection - Over Loading	:	<120%	<120%	<120%	<120%
Protection - Over temperature	:	100 C, shut down o/p voltage, recover automatically after temp is lowered	100 C, shut down o/p voltage, recover automatically after temp is lowered	100 C, shut down o/p voltage, recover automatically after temp is lowered	100 C, shut down o/p voltage, recover automatically after temp is lowered
Working Temperature	:	-40 - +60C	40 - +60C	40 - +60C	40 - +60C
Working Humidity	:	20 - 90% RH, non-condensing	20 - 90% RH, non-condensing	20 - 95% RH, non-condensing	20 - 95% RH, non-condensing
Storage Temp. Humidity	:	-40 - +80 C, 10-95% RH	-40 - +80 C, 10-95% RH	-40 - +80 C, 10-95% RH	-40 - +80 C, 10-95% RH
Temp. coefficient	:	+/-0.03%/C (0 - 50 C)	+/-0.03%/C (0 - 50 C)	+/-0.03%/C (0 - 50 C)	+/-0.03%/C (0 - 50 C)
Vibration	:	10-500Hz, 2G 12 min./1 cycle, period for 72 min. each along X,Y,Z axes	10-500Hz, 2G 12 min./1 cycle, period for 72 min. each along X,Y,Z axes	10-500Hz, 2G 12 min./1 cycle, period for 72 min. each along X,Y,Z axes	10-500Hz, 2G 12 min./1 cycle, period for 72 min. each along X,Y,Z axes
Safety Standards	:	UL8750+UL1310,	10 meters	10 meters	10 meters
Class	:	Class 2 Unit	Class 2 Unit	Class 2 Unit	Class 1 Unit
Withstand Voltage	:	I/P-O/P:1500VAC	I/P-O/P:1500VAC	I/P-O/P:1500VAC	I/P-O/P:1500VAC
Isolation Resistance	:	I/P-O/P: 100MOhm/500VDC/25 C/70%RH	I/P-O/P: 100MOhm/500VDC/25 C/70%RH	I/P-O/P: 100MOhm/500VDC/25 C/70%RH	I/P-O/P: 100MOhm/500VDC/25 C/70%RH
EMC Emission	:	FCC Part 15 B	FCC Part 15 B	FCC Part 15 B	FCC Part 15 B
Net Weight	:	0.21kg driver	1.07kg (driver) + 0.52kg (junction box)	1.2kg (driver) + 0.64kg (junction box)	1.65kg (driver) + 0.73kg (junction box)
Size (LWH) MM	:	1555420 driver	3507737 driver	2307046MM (driver) 3807757MM (jbox)	2567847MM (driver) 4068760MM (jbox)
Packaging MM	:	430375150m 20PCS/Box	430375190 20Pcs/Box	415360190 10Pcs/Box	445350205 10Pcs/Box

1. All parameters if NOT specially mentioned are measured at 120VAC input, rated load and 25C of ambient temperature.

2. To extend the driver's life, please reduce the loading at lower input voltage

3. Loading should be 5 - 100%

DOWNLOADS

Specification Sheet
UL Certificate of Compliance
